LWAE8025SH-01 product photo
LWAE12025SM-02 product photo
LWAE12025SM-02 product photo
  • Frame size80 mm
  • Max airflow39.84 m³/h
  • Max static pressure67.16 Pa
  • Voltage100-240 V
  • Speed4,500 rpm
  • Noise31 dB(A)

LWAE8025SH-01 EC Cooling Fan 80 mm

80 mm | EC | Max airflow 39.84 m³/h | Max static pressure 67.16 Pa | 31 dB(A)

SKU: LWAE8025SH-01 Categories: , ,
  • Factory direct
  • OEM / ODM
  • Samples in 1–3 days
  • Production 15–30 days
  • 18-month warranty
  • CE · ETL · RoHS
View RFQ →
Dimensional drawingDimensions in mm. Confirm against the final approval drawing before machining cut-outs.
LWAE8025SH-01 Dimensional drawing
Performance curve (P-Q)Static pressure vs. airflow. Curve numbers correspond to supply voltage / speed grades.
LWAE8025SH-01 Performance curve (P-Q)

Need a non-standard size or another format? Ask an engineer or search the download center.

LWAE8025SH-01 is a LONGWELL EC Cooling Fan from the EC Cooling Fans range, frame size 80 mm, rated 100-240 V EC, maximum airflow 39.84 m³/h, maximum static pressure 67.16 Pa, noise 31 dB(A). The EC motor integrates the drive electronics: stepless speed control by 0–10 V or PWM signal, speed feedback and high efficiency at part load.

Technical data

Model LWAE8025SH-01
Series LWAE8025
Motor type EC
Phase 1-phase
Rated voltage 100-240 V
Current 0.06 A
Speed 4,500 rpm
Max. airflow 39.84 m³/h
Max. static pressure 67.16 Pa
Noise 31 dB(A)
Frame size 80 mm
Dimensions 80x25mm

Typical applications

  • Power supplies and inverters
  • Telecom and server cabinets
  • Battery packs and EV chargers
  • Medical and laboratory equipment

Series LWAE8025: models in the same series share the impeller and motor platform and differ in speed grade, voltage or lead-out / terminal-box configuration — compare them in the table below or ask for the best fit at your duty point.

Nameplate values: maximum airflow is measured at zero static pressure and maximum static pressure at zero airflow; the two never occur together. Confirm the operating point on the performance curve. Final selection is subject to the duty point (airflow / static pressure / voltage / control mode) and project verification.

Alternatives with the same frame size (80 mm · EC)

Same impeller, different speed grade, power or wiring. Step up for more airflow, step down for lower noise.

ModelMax airflowMax static pressureSpeedPowerNoiseVoltage
LWAE8025SH-01 this model 39.84 m³/h67.16 Pa 4,500 rpm—31 dB(A)100-240 V
LWAE8025SL-03 26.16 m³/h32.23 Pa 3,500 rpm—24 dB(A)100-240 V View
LWAE8025SM-02 33.06 m³/h46.35 Pa 4,000 rpm—27 dB(A)100-240 V View
LWAE8038SL-03 34.26 m³/h47.65 Pa 3,000 rpm—24 dB(A)100-240 V View
LWAE8038SM-02 38.86 m³/h67.05 Pa 3,500 rpm—27 dB(A)100-240 V View
LWAE8038SH-01 41.79 m³/h77.18 Pa 4,000 rpm—31 dB(A)100-240 V View
LWCE-80350SN-06 450 m³/h40 Pa 1,500 rpm16 W51 dB(A)230 V View
LWCE-80520SN-06 650 m³/h59 Pa 1,500 rpm23 W53 dB(A)230 V View
LWCE-80620SN-06 800 m³/h70 Pa 1,500 rpm31 W54 dB(A)230 V View
LWCE-80720SN-06 980 m³/h81 Pa 1,500 rpm39 W55 dB(A)230 V View
LWCE-80820SN-06 1,200 m³/h93 Pa 1,500 rpm52 W56 dB(A)230 V View

Not sure which one? Send us the duty point (airflow / static pressure / noise limit) — use the selector or ask an engineer.
