- ImpellerØ250 mm9.8 in
- Max airflow1,219 m³/h717 CFM
- Voltage110-120 V
- Speed3,000 rpm
- Input power195 W
- Noise69 dB(A)
LWDE-250 (10″)U-MWN-01 EC Mixed Flow Fan Ø250 mm
Ø250 mm | EC | Max airflow 1,219 m³/h | 69 dB(A)
- Factory direct
- OEM / ODM
- Samples in 1–3 days
- Production 15–30 days
- 18-month warranty
- CE · RoHS · ETL on request
LWDE-250 (10")U-MWN-01 is a LONGWELL EC Mixed Flow Fan from the Mixed Flow Fans range, impeller Ø250 mm, rated 110-120 V EC, maximum airflow 1,219 m³/h, noise 69 dB(A), input power 195 W. The EC motor integrates the drive electronics: stepless speed control by 0–10 V or PWM signal, speed feedback and high efficiency at part load.
Technical data
| Model | LWDE-250 (10")U-MWN-01 |
|---|---|
| Series | LWDE250 |
| Motor type | EC |
| Phase | 1-phase |
| Rated voltage | 110-120 V |
| Frequency | 60 Hz |
| Input power | 195 W |
| Speed | 3,000 rpm |
| Max. airflow | 1,219 m³/h |
| Noise | 69 dB(A) |
| Impeller diameter | Ø250 mm |
| Inlet diameter | 250mm |
Typical applications
- Residential and commercial fresh-air systems
- Kitchen and bathroom exhaust
- Local pressurisation and booster duty
- Hotel and office ventilation
Series LWDE250: models in the same series share the impeller and motor platform and differ in speed grade, voltage or lead-out / terminal-box configuration — compare them in the table below or ask for the best fit at your duty point.
Nameplate values: maximum airflow is measured at zero static pressure and maximum static pressure at zero airflow; the two never occur together. Confirm the operating point on the performance curve. Final selection is subject to the duty point (airflow / static pressure / voltage / control mode) and project verification.
Alternatives with the same impeller (Ø250 mm · EC)
Same impeller, different speed grade, power or wiring. Step up for more airflow, step down for lower noise.
| Model | Max airflow | Max static pressure | Speed | Power | Noise | Voltage | |
|---|---|---|---|---|---|---|---|
| LWDE-250 (10")U-MWN-01 this model | 1,219 m³/h | see curve | 3,000 rpm | 195 W | 69 dB(A) | 110-120 V | |
| LWDE-250 (10")U-MWN-03 | 1,219 m³/h | see curve | 3,000 rpm | 195 W | 62 dB(A) | 110-120 V | View |
| LWDE-250S-MBN-07 | 1,231 m³/h | 1,030 Pa | 2,700 rpm | 170 W | 71 dB(A) | 230 V | View |
| LWDE-250 (10")S-MWN-02 | 2,075 m³/h | see curve | 3,000 rpm | 195 W | 69 dB(A) | 220-240 V | View |
| LWDE-250 (10")S-MWN-04 | 2,075 m³/h | see curve | 3,000 rpm | 195 W | 62 dB(A) | 220-240 V | View |
Not sure which one? Send us the duty point (airflow / static pressure / noise limit) — use the selector or ask an engineer.
