- ImpellerØ150 mm
- Max airflow1,350 m³/h
- Max static pressure50 Pa
- Voltage24 V
- Speed100 rpm
- Input power80 W
- Noise62 dB(A)
LWCD-150380MN-06 DC Cross Flow Fan Ø150 mm
Ø150 mm | DC | Max airflow 1,350 m³/h | Max static pressure 50 Pa | 62 dB(A)
- Factory direct
- OEM / ODM
- Samples in 1–3 days
- Production 15–30 days
- 18-month warranty
- CE · ETL · RoHS
Engineering files (on request)
CAD files exist for this model and can be released for assembly checks in SolidWorks / CATIA / Creo / Inventor.
CAD models contain the blade geometry and are not downloadable. Tell us the project; an engineer sends the file after a short check, normally within 1 business day.
LWCD-150380MN-06 is a LONGWELL DC Cross Flow Fan from the DC Cross Flow Fans range, impeller Ø150 mm, rated 24 V DC, maximum airflow 1,350 m³/h, maximum static pressure 50 Pa, noise 62 dB(A), input power 80 W. The low-voltage brushless DC motor suits battery-powered equipment and electronics cooling with speed control on demand.
Technical data
| Model | LWCD-150380MN-06 |
|---|---|
| Series | LWCD15038 |
| Motor type | DC |
| Inlet | Single inlet |
| Rated voltage | 24 V |
| Input power | 80 W |
| Speed | 100 rpm |
| Max. airflow | 1,350 m³/h |
| Max. static pressure | 50 Pa |
| Noise | 62 dB(A) |
| Ambient temperature | -25 ~ 60 °C |
| Impeller diameter | Ø150 mm |
| Outlet length | 380mm |
| Impeller material | Aluminum alloy |
| Insulation class | B |
| Bearing | Maintenance-free ball bearings |
| Duty | S1 |
Typical applications
- Indoor air-conditioning units
- Air curtains and door air barriers
- Elevator and cabinet ventilation
- Linear air supply in appliances
Series LWCD15038: models in the same series share the impeller and motor platform and differ in speed grade, voltage or lead-out / terminal-box configuration — compare them in the table below or ask for the best fit at your duty point.
Nameplate values: maximum airflow is measured at zero static pressure and maximum static pressure at zero airflow; the two never occur together. Confirm the operating point on the performance curve. Final selection is subject to the duty point (airflow / static pressure / voltage / control mode) and project verification.
Alternatives with the same impeller (Ø150 mm · DC)
Same impeller, different speed grade, power or wiring. Step up for more airflow, step down for lower noise.
| Model | Max airflow | Max static pressure | Speed | Power | Noise | Voltage | |
|---|---|---|---|---|---|---|---|
| LWCD-150380MN-06 this model | 1,350 m³/h | 50 Pa | 100 rpm | 80 W | 62 dB(A) | 24 V | |
| LWFD3G150-092SZ-01 | 597 m³/h | 773 Pa | 2,550 rpm | 170 W | 71 dB(A) | 310 V | View |
| LWCD-150500MN-06 | 1,600 m³/h | 63 Pa | 800 rpm | 84 W | 60 dB(A) | 24 V | View |
| LWCD-150700MN-06 | 2,500 m³/h | 83 Pa | 800 rpm | 105 W | 60 dB(A) | 24 V | View |
Not sure which one? Send us the duty point (airflow / static pressure / noise limit) — use the selector or ask an engineer.
