- ImpellerØ350 mm13.8 in
- Max airflow3,467 m³/h2,041 CFM
- Voltage110-120 V
- Speed2,800 rpm
- Input power659 W
- Noise77 dB(A)
LWDE-350 (14″)U-MWN-01 EC Mixed Flow Fan Ø350 mm
Ø350 mm | EC | Max airflow 3,467 m³/h | 77 dB(A)
- Factory direct
- OEM / ODM
- Samples in 1–3 days
- Production 15–30 days
- 18-month warranty
- CE · RoHS · ETL on request
LWDE-350 (14")U-MWN-01 is a LONGWELL EC Mixed Flow Fan from the Mixed Flow Fans range, impeller Ø350 mm, rated 110-120 V EC, maximum airflow 3,467 m³/h, noise 77 dB(A), input power 659 W. The EC motor integrates the drive electronics: stepless speed control by 0–10 V or PWM signal, speed feedback and high efficiency at part load.
Technical data
| Model | LWDE-350 (14")U-MWN-01 |
|---|---|
| Series | LWDE350 |
| Motor type | EC |
| Phase | 1-phase |
| Rated voltage | 110-120 V |
| Frequency | 60 Hz |
| Input power | 659 W |
| Speed | 2,800 rpm |
| Max. airflow | 3,467 m³/h |
| Noise | 77 dB(A) |
| Impeller diameter | Ø350 mm |
| Inlet diameter | 350mm |
Typical applications
- Residential and commercial fresh-air systems
- Kitchen and bathroom exhaust
- Local pressurisation and booster duty
- Hotel and office ventilation
Series LWDE350: models in the same series share the impeller and motor platform and differ in speed grade, voltage or lead-out / terminal-box configuration — compare them in the table below or ask for the best fit at your duty point.
Nameplate values: maximum airflow is measured at zero static pressure and maximum static pressure at zero airflow; the two never occur together. Confirm the operating point on the performance curve. Final selection is subject to the duty point (airflow / static pressure / voltage / control mode) and project verification.
Alternatives with the same impeller (Ø350 mm · EC)
Same impeller, different speed grade, power or wiring. Step up for more airflow, step down for lower noise.
| Model | Max airflow | Max static pressure | Speed | Power | Noise | Voltage | |
|---|---|---|---|---|---|---|---|
| LWDE-350 (14")U-MWN-01 this model | 3,467 m³/h | see curve | 2,800 rpm | 659 W | 77 dB(A) | 110-120 V | |
| LWDE-350 (14")S-MWN-02 | 6,200 m³/h | see curve | 2,800 rpm | 659 W | 77 dB(A) | 220-240 V | View |
Not sure which one? Send us the duty point (airflow / static pressure / noise limit) — use the selector or ask an engineer.
