- ImpellerØ100 mm
- Max airflow410 m³/h
- Voltage110-120 V
- Speed3,350 rpm
- Input power35 W
- Noise52 dB(A)
LWDE-100 (4″)U-PWN-01 EC Mixed Flow Fan Ø100 mm
Ø100 mm | EC | Max airflow 410 m³/h | 52 dB(A)
- Factory direct
- OEM / ODM
- Samples in 1–3 days
- Production 15–30 days
- 18-month warranty
- CE · ETL · RoHS
LWDE-100 (4")U-PWN-01 is a LONGWELL EC Mixed Flow Fan from the Mixed Flow Fans range, impeller Ø100 mm, rated 110-120 V EC, maximum airflow 410 m³/h, noise 52 dB(A), input power 35 W. The EC motor integrates the drive electronics: stepless speed control by 0–10 V or PWM signal, speed feedback and high efficiency at part load.
Technical data
| Model | LWDE-100 (4")U-PWN-01 |
|---|---|
| Series | LWDE100 |
| Motor type | EC |
| Phase | 1-phase |
| Rated voltage | 110-120 V |
| Frequency | 60 Hz |
| Input power | 35 W |
| Speed | 3,350 rpm |
| Max. airflow | 410 m³/h |
| Noise | 52 dB(A) |
| Impeller diameter | Ø100 mm |
| Inlet diameter | 100mm |
Typical applications
- Residential and commercial fresh-air systems
- Kitchen and bathroom exhaust
- Local pressurisation and booster duty
- Hotel and office ventilation
Series LWDE100: models in the same series share the impeller and motor platform and differ in speed grade, voltage or lead-out / terminal-box configuration — compare them in the table below or ask for the best fit at your duty point.
Nameplate values: maximum airflow is measured at zero static pressure and maximum static pressure at zero airflow; the two never occur together. Confirm the operating point on the performance curve. Final selection is subject to the duty point (airflow / static pressure / voltage / control mode) and project verification.
Alternatives with the same impeller (Ø100 mm · EC)
Same impeller, different speed grade, power or wiring. Step up for more airflow, step down for lower noise.
| Model | Max airflow | Max static pressure | Speed | Power | Noise | Voltage | |
|---|---|---|---|---|---|---|---|
| LWDE-100 (4")U-PWN-01 this model | 410 m³/h | see curve | 3,350 rpm | 35 W | 52 dB(A) | 110-120 V | |
| LWDE-100S-MBN-10 | 324 m³/h | 927 Pa | 3,300 rpm | 85 W | 72 dB(A) | 230 V | View |
| LWDE-100 (4")U-MWN-03 | 410 m³/h | see curve | 3,350 rpm | 35 W | 51 dB(A) | 110-120 V | View |
| LWDE-100 (4")S-PWN-02 | 697 m³/h | see curve | 3,350 rpm | 35 W | 52 dB(A) | 220-240 V | View |
| LWDE-100 (4")S-MWN-04 | 697 m³/h | see curve | 3,350 rpm | 35 W | 51 dB(A) | 220-240 V | View |
| LWCE-100380SN-06 | 800 m³/h | 106 Pa | 1,500 rpm | 32 W | 55 dB(A) | 230 V | View |
| LWCE-100520SN-06 | 1,100 m³/h | 145 Pa | 1,500 rpm | 55 W | 58 dB(A) | 230 V | View |
| LWCE-100620SN-06 | 1,300 m³/h | 173 Pa | 1,500 rpm | 70 W | 59 dB(A) | 230 V | View |
| LWCE-100720SN-06 | 1,530 m³/h | 201 Pa | 1,500 rpm | 75 W | 60 dB(A) | 230 V | View |
| LWCE-100820SN-06 | 1,735 m³/h | 229 Pa | 1,500 rpm | 80 W | 61 dB(A) | 230 V | View |
Not sure which one? Send us the duty point (airflow / static pressure / noise limit) — use the selector or ask an engineer.
