- ImpellerØ125 mm
- Max airflow697 m³/h
- Voltage220-240 V
- Speed3,350 rpm
- Input power35 W
- Noise51 dB(A)
LWDE-125 (5″)S-MWN-04 EC Ultra Silent Metal Duct Fan Ø125 mm
Ø125 mm | EC | Max airflow 697 m³/h | 51 dB(A)
- Factory direct
- OEM / ODM
- Samples in 1–3 days
- Production 15–30 days
- 18-month warranty
- CE · ETL · RoHS
LWDE-125 (5")S-MWN-04 is a LONGWELL EC Ultra Silent Metal Duct Fan from the Ultra Silent Duct Fans range, impeller Ø125 mm, rated 220-240 V EC, maximum airflow 697 m³/h, noise 51 dB(A), input power 35 W. The EC motor integrates the drive electronics: stepless speed control by 0–10 V or PWM signal, speed feedback and high efficiency at part load.
Technical data
| Model | LWDE-125 (5")S-MWN-04 |
|---|---|
| Series | LWDE125 |
| Motor type | EC |
| Phase | 1-phase |
| Rated voltage | 220-240 V |
| Frequency | 50 Hz |
| Input power | 35 W |
| Speed | 3,350 rpm |
| Max. airflow | 697 m³/h |
| Noise | 51 dB(A) |
| Impeller diameter | Ø125 mm |
| Inlet diameter | 125mm |
Typical applications
- Residential and commercial fresh-air systems
- Kitchen and bathroom exhaust
- Local pressurisation and booster duty
- Hotel and office ventilation
Series LWDE125: models in the same series share the impeller and motor platform and differ in speed grade, voltage or lead-out / terminal-box configuration — compare them in the table below or ask for the best fit at your duty point.
Nameplate values: maximum airflow is measured at zero static pressure and maximum static pressure at zero airflow; the two never occur together. Confirm the operating point on the performance curve. Final selection is subject to the duty point (airflow / static pressure / voltage / control mode) and project verification.
Alternatives with the same impeller (Ø125 mm · EC)
Same impeller, different speed grade, power or wiring. Step up for more airflow, step down for lower noise.
| Model | Max airflow | Max static pressure | Speed | Power | Noise | Voltage | |
|---|---|---|---|---|---|---|---|
| LWDE-125 (5")S-MWN-04 this model | 697 m³/h | see curve | 3,350 rpm | 35 W | 51 dB(A) | 220-240 V | |
| LWDE-125S-MBN-06 | 386 m³/h | 839 Pa | 3,400 rpm | 85 W | 69 dB(A) | 230 V | View |
| LWDE-125 (5")U-PWN-01 | 410 m³/h | see curve | 3,350 rpm | 35 W | 52 dB(A) | 110-120 V | View |
| LWDE-125 (5")U-MWN-03 | 410 m³/h | see curve | 3,350 rpm | 35 W | 51 dB(A) | 110-120 V | View |
| LWDE-125 (5")S-PWN-02 | 697 m³/h | see curve | 3,350 rpm | 35 W | 52 dB(A) | 220-240 V | View |
Not sure which one? Send us the duty point (airflow / static pressure / noise limit) — use the selector or ask an engineer.
